Our knurled head MTCG nuts with metric thread, similar to DIN 466, are manufactured in various engineered materials that promote properties such as chemical resistance , mechanical, oxidation, etc.

These nuts with knurled heads are available in PA66 (Polyamide 66 “Nylon”), PP (Polypropylene), POM (Acetal Resin), < b>PVDF (Polyvinylidene Fluoride), PEEK (Polyetheretherketone) and PAGF (Polyamide with the possibility of up to 50% fiberglass).

 Produkowane w kolorach RAL

Rysunki PDF:
UL94:   V2
IP:
RoHS:
Jednostka miary:: Milimetry


Numer katalogowy
Gwint metryczny
A
B
C
Similar DIN



Więcej
info.
03100300600 M3 12,00 7,00 3,50 DIN 466
00100101104 M4 10,80 8,00 3,50 DIN 466
03100300601 M4 12,00 7,00 3,50 DIN 466
03100300603 M4 16,00 8,00 4,50 DIN 466
03100300602 M5 14,00 7,00 3,50 DIN 466
03100300604 M5 16,00 8,00 4,50 DIN 466
03100300605 M5 19,30 11,30 6,15 DIN 466
03100300606 M6 16,00 8,00 4,50 DIN 466
03100300607 M6 19,00 6,00 6,00 DIN 466

Jeśli są Państwo zainteresowani częściami z rodziny MTCG, mogą być Państwo również zainteresowani tymi oto rodzinami cześci:

Our MTCH metric thread screws with <b>hex head</b> <i>(Hex Head)</i>, similar to <b>DIN 34810 (DIN 933) / ISO 4017</b>, are manufactured in various <b>engineering materials</b> that promote properties such as chemical, mechanical, oxidation resistance, etc.<br><br>
These hexagonal screws are available in <b>PA66</b> (Polyamide 66 “Nylon”), <b>PP</b> (Polypropylene), <b>POM</b> (Acetal Resin), <b> PVDF</b> (Polyvinylidene Fluoride), <b>PEEK</b> (Polyetheretherketone) and <b>PAGF</b> (Polyamide with the possibility of up to 50% fiberglass).<br>< br>
<i>The measurements of M2 and M2.5 are supplied only in PA66.</i><br>   Nasze śruby z łbem szczelinowym <b>DIN 84 / ISO 1207</b> wyprodukowane w <b>PA66</b>, zapewniają doskonałą odporność na działanie substancji chemicznych (patrz tabela właściwości). Są wykonane z materiału o wysokim stopniu wytrzymałości dielektrycznej, nie rdzewieją i zapobiegają uszkodzeniom podczas obciążeniom mechanicznym.   MVR slotted metric threaded studs (similar to DIN 551), are manufactured in <b>PA66</b>, an ideal material for most applications, offering excellent resistance to chemical products (see technical data sheet), high level of dielectric strength, does not rust and prevents damage caused by overvoltage.
<br>   Tulejki TI stosowane są w wielu aplikacjach wymagających mechanicznej izolacji lub jako łożyska ślizgowe. Pozwalają one zredukować wibracje i tarcie, są odporne na korozję oraz promieniowanie UV. Mogą być produkowane w niestandardowych kolorach oraz wymiarach. Na specjalne zamówienie istnieje możliwość wyposażonia ich w taśmę dwustronnie klejącą dla łatwiejszego montażu. Wykonywane z wysokiej jakości tworzyw PA6, PA66 lub LDPE.   TU washers and spacers are used in a multitude of mechanical and insulation applications, whose manufacturing is carried out in various <b>engineering materials</b> that favor properties such as <i>chemical, mechanical, oxidation resistance, etc. .</i>, and are available in <b>PA</b> -Polyamide 6 and 66 (Nylon)-, <b>PP</b> -Polypropylene-, <b>POM</b> -Resin Acetal-, <b>PVDF</b> -Polyvinylidene Fluoride-, <b>PTFE</b> - Polytetrafluoroethylene (Teflon™)-, <b>PEEK</b> -Polyetheretherketone-, <b>LDPE</b> -Low Density Polyethylene- and <b>PAGF</b> -<i>Nylon with the possibility of up to 50% fiberglass-</i>.
<br>
We also supply upon request some measurements with an adhesive disc on both sides to fix and facilitate assembly during the installation process.
<br>
Contact us for more information and to check the availability of the references of your interest in the materials and colors indicated.
